Photo Title:: Some of the Dunblane 53A points panels laid onto the existing track before positioning.
Description:: Some of the Dunblane 53A points panels laid onto the existing track before positioning. The tilting points carrier wagon set comes with its own mechanically armed lifting beam to enable a Kirow to lift the panels off the wagons within the restricted crane jib movement window but this is too rigid for final placement where the Kirow uses one of its own lifting beams and traditional chains. 02.09.23
Gallery:: Infrastructure
Uploaded:: Sunday 03 of September, 2023 [15:06:13 UTC] by jwwemyss
